HBP1800 OS Series (1.2-3KW)

Office Power Station 1280Wh 2560Wh 3072Wh

The HBP1800 OS series is specifically designed for office use, providing a reliable and efficient power source. However, it is also versatile enough to power various household appliances, including phone, laptops, stereos, and desktop computers. Equipped with a built-in LiFePO4 battery, the HBP1800 OS has a capacity of either 1280~3072Wh, Multiple DC output ports for Multiple Devices, Plug & play, making it an ideal portable power station for a range of needs.

Category: Portable Power Station Tags: European ESS, European Products, Power Station

Description

■ Energy storage 1280~3072wWh Optional

■ 6000+ Charge cycle @ 80% DOD,25°C

■ 1~3KW Pure sine wave inverter

■ Multiple DC output ports for Multiple Devices, Plug & play

■ Flexible Recharging Ways (AC/ Solar)

■ Built in Multi safety protection

MODEL		HBP18-1012 OS	HBP18-2024 OS	HBP18-3024 OS
Nominal Battery System Voltage		12VDC	24VDC	24VDC
INVERTER OUTPUT
Rated power		1200W	2000W	3000W
Output voltage waveform		Pure Sine Wave
Output voltage regulation		230V ±5%
Output frequency		50Hz / 60Hz (±0.2Hz)
Peak efficiency		90%
Nominal DC input voltage		12V (±0.3)	24V (±0.3)	24V (±0.3)
Standby Consumption		< 25W
PV INPUT
Max solar power input		900W	1800W	1800W
PV max charging current		60A (±3A)	60A (±3A)	60A (±3A)
Combined charging current		70A (±4A)	70A (±4A)	80A (±4A)
Max efficiency		98.0% max
PV array open circuit voltage		105VDC	160VDC	160VDC
PV Array MPPT Voltage Range		15~105V	30~128VDC	30~128VDC
AC INPUT
AC input voltage		230Vac ±5%
Acceptable input voltage range		90-280VAC
Nominal input frequency		50Hz / 60Hz (Auto detection)
Transfer time		10ms typical (UPS, VDE); 20ms typical (APL)
AC CHARGE
Charging current @ Nominal input voltage		20A (±4A)	40A/(±4A)	60A (±4A)
Charging Algorithm		4-step (Li)
OUTPUT
AC output		230Vac (Socket *3pcs)
USB TypeC		DC output*1pcs
USB-A 12V/1A		DC output*2pcs
USB-A 5V		DC output*4pcs
LITHIUM BATTERY
Energy		1280Wh	2560Wh	3072Wh
Nominal voltage		12.8V	25.6V	25.6V
Battery capacity		100Ah	100Ah	120Ah
Protection board		100A	100A	150A
Standard charging & discharge current		50A	50A	50A
Operation temperature	Charge	0°C to 45°C
	Discharge	-10°C to 60°C
MECHANICAL SPECIFICATIONS
Machine Dimension (WHD)(mm)		225295363	275324403	288348490
Package Dimension (WHD)(mm)		440305355	485356420	570370445
N.W(kg)		17	24	33
G.W(kg)		18.5	26	36
Standard Warranty		Inverter: 2 years ; Lithium battery: 5 years
CERTIFICATION & STANDARDS
CE-EMC+LVD(EN6100-6-3;2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
